Planeo 60 Pro Comfort Sliding Door System

Manual sliding door system with running rails sliding invisibly in the profile. Can be used for 1 or 2 leaf sliding glass doors. Glass Panes are securely clamped and do not require any special preparation. The soft closing operation gently guides the doors into their end position and holds them there.
The system is prepared for installation to the wall and can be easily installed by frontal attachment of the door.

Tested in accordance with
DIN EN 1527:2013



What makes this kit so great? NO pre drilling of glass is required.... The glass is held by clamps!!

Strong self adhesive flush pulls & pull handles are available

  • Rail Type Profile
  • Wall Mounted
  • Height Adjustable
  • Max Door Weight 60kg
  • Min Door Width 850mm
  • Suitable for 8mm glass
  • Suitable for 10mm glass
  • Finish SSO
  • Rail Dimension 46 x 63mm
  • 1 Leaf Option
  • 2 Leaf Option
  • Soft Close
  • Standard Length 2000 or 4000mm
  • Optional Length(special order) 2500mm
  • DIN EN 1527 100,000cycles
  • Wall distance(door-wall) glass 20.5mm
  • Optional skirting/Architrave Spacer Kit 12.5mm
